| ชื่อแบรนด์: | XIWUER |
| หมายเลขรุ่น: | 20kV-10000pf |
| MOQ: | 1 ชิ้น |
| ราคา: | โปร่ง |
| เงื่อนไขการชำระเงิน: | , l/c, t/t |
| ความสามารถในการจัดหา: | 4,000,000 ชิ้นต่อปี |
| เลขที่ | ข้อมูลจำเพาะ | การกระจาย | แรงดันไฟฟ้าทนทาน | ความต้านทานฉนวน | ขนาด (มม.) |
|---|---|---|---|---|---|
| 1 | 20kV-2000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:45 | H:19 | L:23 | D:12 | M:5 |
| 2 | 20kV-10000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:65 | H:15 | L:19 | D:12 | M:5 |
| 3 | 20kV-18000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:80 | H:17 | L:25 | D:12 | M:5 |
| 4 | 30kV-1000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:45 | H:24 | L:32 | D:12 | M:4 |
| 5 | 30kV-2700pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:60 | H:20 | L:28 | D:12 | M:4 |
| 6 | 30kV-12000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:45 | H:19 | L:23 | D:12 | M:5 |
| 7 | 40kV-150pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:74 | H:18 | L:26 | D:12 | M:5 |
| 8 | 40kV-500pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:28 | H:33 | L:41 | D:8 | M:4 |
| 9 | 40kV-7500pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:80 | H:24 | L:29 | D:12 | M:6 |
| 10 | 40kV-10000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:80 | H:22 | L:26 | D:16 | M:5 |
| 11 | 50kV-1000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:50 | H:30 | L:34 | D:12 | M:4 |
| 12 | 50kV-1000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:32 | H:27 | L:31 | D:16 | M:5 |
| 13 | 50kV-1000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:80 | H:31 | L:35 | D:16 | M:5 |
| 14 | 50kV-1000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:50 | H:31 | L:34 | D:12 | M:5 |
| 15 | 50kV-1000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:65 | H:32 | L:35 | D:16 | M:5 |
| 16 | 50kV-1000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:50 | H:54 | L:58 | D:12 | M:5 |
| 17 | 100kV-2000pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:51 | H:32 | L:35 | D:16 | M:5 |
| 18 | 100kV-1500pF(ชนิดฉนวน) | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:68 | H:36 | L:40 | D:16 | M:5 |
| 19 | 150kV-820pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:65 | H:95 | L:100 | D:12 | M:5 |
| 20 | 200kV-600pF | ≤0.0040 | 1.5Ur● 1min | ≥1.0 x 105MΩ | D:50 | H:90 | L:94 | D:16 | M:5 |
